A Spatial Variogram Function for Single Site Data — directional

This function allows you to observe directional variograms in the 0 (vertical) and 90 (horizontal) directions for gridded small-plot trial data.

Usage

directional_variograms(model)

Arguments

model: asreml A model with some residual structure.

Value

gstat::variogram A Gstat variogram.

Examples

library(asreml)
model <- asreml(
    fixed = yield ~ weed,
    random = ~idv(Variety),
    residual = ~ar1v(Row):id(Column),
    data = wheat
)
mod <- directional_variograms(model)
plot(mod, multipanel = FALSE)


if (FALSE) { # \dontrun{
# You can also plot using ggplot if you wish
ggplot(
    mod,
    aes(x = dist, y = gamma, group = dir.hor, colour = factor(dir.hor))
) +
    geom_point() +
    geom_line() +
    facet_grid(~dir.hor, scales = "free_x")
} # }
